4,7µF 63V Axial

Availability:

In stock (30)

• CAPACITOR, 4.7UF, 63V
• Capacitor Dielectric Type:Aluminium Electrolytic
• Capacitance:4.7µF
• Capacitance Tolerance:± 20%
• Voltage Rating:63VDC
• Life Time @ Temperature:2000 hours @ 85°C
• Height:12mm
• Outer Diameter:5mm
• Capacitor Case Style:Axial
• No. of Pins:2
• Operating Temperature Range:-40°C to +85°C
• SVHC:No SVHC (18-Jun-2010)
• AC Ripple Current:37mA
• Applications:General Purpose
• Body Diameter:5mm
• External Length / Height:12mm
• Lead Diameter:0.6mm
• Lead Length:35mm
• Operating Lifetime:2000h
• Operating Temperature Max:85°C
• Package / Case:Axial
• Ripple Current Frequency:120Hz
• Ripple Current Temperature:85°C
• Temperature Operating Min:-40°C
• Terminal Type:Wire Ended
• Tolerance +:20%
• Tolerance -:20%
• Voltage DC:63V
