Nichicon 33µF 63V Axial

€0,80
Availability: In stock (15)

CAPACITOR, 33UF, 63V

  • Capacitance: 33µF
  • Capacitance Tolerance: ± 20%
  • Voltage Rating: 63V
  • Life Time @ Temperature: 2000 hours @ 85°C
  • Height: 16mm
  • Diameter: 6.3mm
  • Capacitor Mounting: Through Hole
  • Capacitor Terminals: Axial Leaded
  • Operating Temperature Range: -40°C to +85°C
  • SVHC: No SVHC (20-Jun-2011)
  • AC Ripple Current: 120mA
  • External Length / Height: 16mm
  • Lead Diameter: 0.6mm
  • Lead Length: 35mm
  • No. of Pins: 2
  • Operating Lifetime: 2000h
  • Operating Temperature Max: 85°C
  • Operating Temperature Min: -40°C
  • Ripple Current Frequency: 120Hz
  • Ripple Current Temperature: 85°C
  • Terminal Type: Wire Ended
  • Tolerance +: 20%
  • Tolerance -: 20%
  • Voltage Rating V DC: 63V
