4700µF 25V 22mm Snap-in Multicomp

€1,40
Availability: In stock (8)



  • CAPACITOR, 4700UF, 25V
  • Capacitor Dielectric Type:Aluminium Electrolytic
  • Capacitance:4700µF
  • Capacitance Tolerance:± 20%
  • Voltage Rating:25V DC
  • Series:MCLPR
  • Life Time @ Temperature:2000 hours @ 85°C
  • Height:25mm
  • Outer Diameter:22mm
  • Capacitor Case Style:Radial Snap-in
  • No. of Pins:2
  • Mounting Type:Through Hole
  • Lead Spacing:10mm
  • Operating Temperature Range:-40°C to +85°C
  • AC Ripple Current:2.5A
  • Applications:General Purpose
  • Body Diameter:22mm
  • External Length / Height:25mm
  • Operating Life Temperature:85°C
  • Operating Lifetime:2000h
  • Operating Temperature Max:85°C
  • PCB Hole Diameter:2mm
  • Package / Case:Radial
  • Ripple Current Frequency:120Hz
  • Ripple Current Temperature:85°C
  • Temperature Operating Min:-40°C
  • Terminal Type:Snap-In
  • Tolerance +:20%
  • Tolerance -:20%
  • Voltage DC:25V
0 stars based on 0 reviews
